| Tempat asal: | Jiangsu |
|---|---|
| Nama merek: | XINFUTIAN |
| Sertifikasi: | ISO,BV |
| Nomor model: | 65 #, 70 #, 82b kawat pegas karbon tinggi |
| Kuantitas min Order: | 5 Ton |
| Harga: | Negotiation |
| Kemasan rincian: | Paket standar layak laut atau sebagai kebutuhan pelanggan |
| Waktu pengiriman: | 5-10 hari kerja |
| Menyediakan kemampuan: | 1000 Ton per bulan |
| Nama Produk: | kabel baja pegas | Toleransi: | ± 1% |
|---|---|---|---|
| Permukaan: | hitam / cerah | Ukuran: | Diameter 5-40mm |
| Pemakaian: | Untuk Musim Semi | Bahan: | Baja paduan |
| Cahaya Tinggi: | Kawat baja pegas 40mm,kawat baja karbon 40mm,kawat baja pegas HDG |
||
High Tensile Hot mencelupkan kawat baja pegas karbon kawat baja
|
Produk
|
High Tensile Hot mencelupkan kawat baja pegas karbon kawat baja |
|
Kualitas baja
|
1066 9255 9260 5155 5160 6150 51B80 SUP6 SUP9 SUP9A SUP10A SUP11 55Si7 60Si7 55Cr3 51CrV4 58CrMnB4
|
|
Standar
|
DIN17223-1-1984, EN10270-1, ASTM-A227, GB4357-89
|
|
Proses
|
QT Oil Hardened / Dipatenkan / Cold Drawing
|
|
Permukaan
|
Hitam / Cerah
|
|
Ukuran
|
Diameter 5-40mm
|
|
Sertifikat
|
3.1 Sertifikat Produsen
|
|
Paket
|
Coil (Berat setiap kumparan: 40 - 1.000 kg)
|
|
Aplikasi
|
(1) kasur pegas
(2) pegas kompresi (3) pegas ekstensi (4) pegas torsi (5) pegas mekanis (6) bentuk kawat (7) inti kabel pengontrol (8) kabel penghubung (9) jarum keras |
| Kabel baja pegas karbon | |||
| High Tensile Hot mencelupkan kawat baja pegas karbon kawat baja | GB4357-1989 | ||
| Diameter mm | Kekuatan Tarik, MPa | ||
| B | C | D | |
| 0.22 | 2110-2500 | 2350-2750 | 2690-3090 |
| 0.25 | 2060-2450 | 2300-2700 | 2640-3040 |
| 0.28 | 2010-2400 | 2300-2700 | 2640-3040 |
| 0.30 | 2010-2400 | 2300-2700 | 2640-3040 |
| 0.32 | 1960-2350 | 2250-2650 | 2600-2990 |
| 0.35 | 1960-2350 | 2250-2650 | 2600-2990 |
| 0.40 | 1910-2300 | 2250-2650 | 2600-2990 |
| 0.45 | 1860-2260 | 2200-2600 | 2550-2940 |
| 0,50 | 1860-2260 | 2200-2600 | 2550-2940 |
| 0,55 | 1810-2210 | 2150-2550 | 2500-2890 |
| 0.60 | 1760-2160 | 2110-2500 | 2450-2840 |
| 0.63 | 1760-2160 | 2110-2500 | 2450-2840 |
| 0.70 | 1710-2110 | 2060-2450 | 2450-2840 |
| 0.80 | 1710-2060 | 2010-2400 | 2400-2840 |
| 0.90 | 1710-2060 | 2010-2350 | 2350-2750 |
| 1.00 | 1660-2010 | 1960-2300 | 2300-2690 |
| 1.20 | 1620-1960 | 1910-2250 | 2250-2550 |
| 1.40 | 1620-1910 | 1860-2210 | 2150-2450 |
| 1.60 | 1570-1860 | 1810-2160 | 2100-2400 |
| 1.80 | 1520-1810 | 1760-2110 | 2010-2300 |
| 2.00 | 1470-1760 | 1710-2010 | 1910-2200 |
| 2.20 | 1420-1710 | 1660-1960 | 1810-2110 |
| 2.50 | 1420-1710 | 1660-1960 | 1760-2060 |
| 2.80 | 1370-1670 | 1620-1910 | 1710-2010 |
| 3.00 | 1370-1670 | 1570-1860 | 1710-1960 |
| 3.20 | 1320-1620 | 1570-1810 | 1660-1910 |
| 3.50 | 1320-1620 | 1570-1810 | 1660-1910 |
| 4.00 | 1320-1620 | 1570-1760 | 1620-1860 |
| 4.50 | 1320-1570 | 1520-1760 | 1620-1860 |
| 5.00 | 1320-1570 | 1470-1710 | 1570-1810 |
| 5,50 | 1270-1520 | 1470-1710 | 1570-1810 |
| 6.00 | 1220-1470 | 1420-1660 | 1520-1760 |
